Developing a novel class of vaccine is pivotal for eliminating and eradicating malaria. Preceding investigations demonstrated partial blocking activity in malaria transmission against recombinant vaccine PfHAP2-GCS1 and conserved region of the cd loop. The effectiveness of immune response varies with the size and shape of the self-assembly of peptide nanoparticles (SAPNs) displaying antigen, affected by different components in refolding buffers. Plasmodium falciparum Generative Cell Specific 1 (PfGCS1), a promising malaria transmission-blocking vaccine (TBV) candidate, was expressed, purified, and followed by a four-step refolding process to form nanoparticles (PfGCS1-SAPNs). The influence of buffer components on the size and shape of SAPNs was investigated by DLS and FESEM. Furthermore, the immunogenicity of nanostructures was assessed in different mouse groups. The results showed that PfGCS1-SAPN was immunogenic and its administration with Poly (I:C), stimulated humoral and cellular responses in the mouse model. In the immunized mice groups, the level of IgG antibodies against PfGCS1-SAPN was significantly increased in different time points (second and third boost) and heterogeneous boosters. The various IgG-subclasses profile shifted to Th1, Th2, or Th1/Th2 mix responses in mice immunized with PfGCS1-SAPN refolded in different buffers, indicating a prerequisite for further investigations to optimize vaccine formulation to enhance and modulate Th1/cellular responses. Such studies pave the way to improve biophysical features related to the nanoparticles size, shape, and conformational epitopes of candidate antigens and T- and B-cells presented on the superficial structure to elicit robust immune responses.
